Projects

OEM SOLUTIONS FOR HVAC MANUFACTURERS

Most of the work we do at Temco is behind the scenes development and manufacturing work for large air conditioning companies. But we’ve done work on many projects unrelated to air conditioning such as a custom wind turbine controller, sports testing equipment, a depth sounder for the commercial fishing industry a laser range finder and a floor cleaning machine controller to name a few. If you have a project that you are making already, or want to see what it would cost to have a certain widget made up to your specs, feel free to send your NDA our way and we’ll get the quote started. Our electronics, software and mechanical engineers will make your project a success. Your budget will go further which can make your product better, not just cheaper.

  • Timing Gate
  • Custom Relay Board
  • Bacnet Boiler Controller
  • Outdoor Sensor
  • PWM Transducer

Timing gate project

Features successfully implemented:

  • Impact and water resistant
  • Millisecond accuracy
  • Multi-lane capable
  • Instant feedback
  • Wireless system integration
  • Reaction test directional arrows
  • Rechargeable 24-hour battery life
  • Superbright LED indicators
  • Continuous synchronization
  • Versatile test creation for all sports

Future improvements:



Back to Top

Custom Relay Board

Features successfully implemented:

  • Works with positive and negative ground systems
  • Jumpers can set to two different operations
  • Modes: common switched 24VAC or dry contact
  • Panel mount base, removable face plate
  • LED for low voltage relay

Future improvements:





Back to Top

Bacnet Boiler Controller

Features successfully implemented:

  • High voltage pumps connect directly no external relays to install & wire
  • Baseplate is passive all electronics are in the removable lid
  • 10 pluggable relays for low or line voltage switching
  • 16 universal inputs, 0-5V, 0-10V, thermister can be configured by software. 8digital inputs(24V AC) or 8 thermostat which can be adjusted by jumper
  • 8 thermostats direct connect over RS485, more via subnet or by adding more boiler controller
  • Open source front end software, free download and no licensing fees
  • Bacnet over ethernet TCP and RS485 MSTP
  • Modbus over IP and RS485 RTU

Future improvements:



Back to Top

OUTDOOR SENSOR

Features successfully implemented:

  • Light sensor, Humidity sensor, Temperature sensor
  • 3 point humidity calibration
  • In System Programmable over the network communication

Future improvements:



Back to Top

PWM TRANSDUCER

Features successfully implemented:

  • Convert a 0~10seconds input pulse to a 0~10Vdc signal
  • Manual/OFF/Auto operational states
  • Optional RS485 communication
  • Input to Output Signal Isolated
  • Input Edge Triggered Activated
  • Pulse to Analog Transducer
  • Interface to Electric Actuator
  • Drive Variable Speed Pump Control
  • Drive Variable Frequency Fan Control
  • Dial potentiometer for manual override of output

Future improvements:



Back to Top
