Description
Probe Temperature Sensor
Size：
.JPG)
Size：
Part Number Scheme：
Probe Temperature Sensor
This Probe Temperature Sensor comes standard with a 15mm Stainless Steel Temperature Sensor. This sensor is a 10K Thermistor, with an industry standard Type 2 curve.Connected to the end of the Sensor is 2 UL2468 26/2CAWG 105°C Black Wires with tinned ends.
Product Highlights:
- Many ranges available. Standard range is 10k type2
- Accuracy is ±0.2C
- Temperature Range: -40℃ to125℃
- Insulated Resistance: >100MΩ,500VDC in water
- Breakdown Voltage: 1500VAC, 1min
- UL listed Cable,UL file NO.2468
$2.20 - $3.80
Available Options:
Part Number Scheme：
Additional information
| Weight | 0.03 kg |
|---|---|
| Temperature Type | Probe Temperature Sensor |
| Probe Length | 0.6 inch, 4 inch |
| Temperature Curve | 10K Type 2, 10K Type 3, 1K PT |
